IRS-XS 3520 — high-precision sheet leveling machine designed to eliminate internal stresses and straighten metal sheets with thickness from 0.3 mm to 5 mm and width up to 200 mm. The equipment delivers excellent results when processing various types of metals, improving quality and precision in subsequent manufacturing processes.
Technical Specifications:
- Material thickness: 0.3–5 mm
- Maximum sheet width: 200 mm
- Minimum part length: 70 mm
- Gap adjustment system: electromechanical, PC-controlled
- Quick roller replacement: optional
- Overload protection: not provided
- Control: touchscreen
- CE compliance: yes
- Machine dimensions (L×W×H): 1585×1585×1820 mm
- Weight: 2,850 kg
Dimensions:
- A: 1710 mm
- B: 1400 mm
- C: 2230 mm
- D: 250 mm
- E: 990 mm
- F: 1330 mm
- G: 780 mm
- H: 965 mm
Advantages of the IRS-XS 3520 Sheet Leveling Machine:
- High leveling accuracy: eliminates internal stresses and achieves the required flatness of the material.
- Electromechanical gap adjustment: allows precise setting of processing parameters via PC, ensuring repeatable results.
- Optional quick roller replacement: enables fast reconfiguration for processing different materials.
- Compact dimensions: allow integration into limited production spaces.
- Intuitive control: touchscreen simplifies setup and monitoring of the working process.
Applications:
The IRS-XS 3520 sheet leveling machine is used in various industries, including:
- Automotive industry: leveling body and chassis parts to ensure assembly precision.
- Home appliance manufacturing: processing metal panels for device housings.
- Electronics industry: leveling thin metal components for accurate assembly.
- Metalworking: preparing sheet material for cutting, welding, or bending operations.
Using this machine improves product quality, reduces rework costs, and increases production efficiency.
